Wholesale High Brightness 6.2inch 800X480dots TFT LCD Display
Display model XX062H088-50M309-21T is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel and a driving circuit.
This TFT LCD has a 6.2 (16:9) inch diagonally measured active display area with 800 horizontal by 480 vertical pixel resolutions.
PRODUCT DESCRIPITION
| Panel Brand | ROYAL |
| Panel Model | XX062H088 |
| Panel Type | TFT-LCD , Panel |
| Panel Size | 6.2 inch |
| Resolution | 800*480 |
| Display Mode | Normally White |
| Brightness | 550nits (Typ.) |
| Outline Dimension | 155.20x88.20x5.00mm |
| Display area | 137.52(H)x77.232(V)mm |
| Pixel pitch | 0.1719(H)x0.1609(V) |
OUR SERVICE ADVANTAGES
1. Small order would be accepted.
2. Mass production lead time would be guaranteed.
3. Each order will have 0.2%-0.5% spare.
4. Even customers do not have a cooperation with us, we also can provide technical services.
5. If mass production has any quality problem, customer can return it.
6. Got many good reviews from our customers.
ACCESSORIES
Royal Display can provide many accessories to go with your display. If you would like to source a connector, cable, test jig or other accessory preassembled to your LCD (or just included in the package), our team will make sure you get the items you need. Get in touch with a team member today to accessorize your display!
WARRANTY
Product Tags:
|
|
6.2 Inch 800X3(RGB)X480 Dots TFT LCD Display 550nits Lcd Panel Module With White Blacklight Images
|
